What this practice actually looks like.
Parts, assemblies, layouts, illustration, packaging, and structures — the class of work CADCraft models and details. Representative, not a client’s files.
CC-01 · Parts
Parts and hole patterns
A plate, a bracket, a pattern of holes — modeled and drawn so the mill and the bolt circle agree.
CC-02 · Structures
Welded frames and structures
Weldment models with cut lists, end preps, and drawings a fabricator can quote from.
CC-03 · Layouts
Project and beam layouts
Benches, beam paths, and full-project arrangements modeled so every piece has a place and a keep-out.
CC-04 · Illustration
Proposal and device illustration
Concept and functional-device figures for proposals — plus scientific and how-it-works views from the same CAD.
CC-05 · Packaging
Housings and packaging
The box around the thing: covers, cooling, connectors, and what a person can actually reach.
CC-06 · Interfaces
Mechanical interfaces
Flanges, chambers, and mating interfaces modeled to the standard the shop already buys from.
